CPCD30 Diesel Forklift Truck

Engine Parts

Introduction

This series diesel forklift adopts the up to date appearance design, featuring streamline, dynamic and stylish appearance.
Large sized covering part made by injection molding process makes the lift truck more elegant and user friendly.
Owing to long wheelbase design, the lifting equipment comes with higher longitudinal stability and more than 100kg lifting weight higher than the original forklift truck at the same lifting height. Additionally, the load on the real axle is reduced, extending the service life of steering wheel.
Reduction of front and rear overhang size ensures smaller turning radius and lower width of passage for right angle stacking, thus improving warehouse use ratio.
The diesel forklift is available in Japanese OKAMURA, NISSAN and Chinese HC transmissions that come with best in class structure and reliable performance. Amongst these transmissions, the OKAMURA type adopts the state of the art floating structure, ensuring completely flexible connection between engine and forklift frame, thus minimizing vibration.

Features

Unbeatable Services

Testing and commissioning will be carried out before delivery

The delivery cycle conventional products is 30 days

Under warranty is One year after they are purchased or 2000 working hours.

Provide corresponding theoretical and practical training solution

Parameter

CPCD30 Diesel Forklift Truck Parameter

General	Product name							Forklift truck
	Basic model							CPCD30
	Type							RW6	RW6B	RW10	RW10B	RW13		RW15A	RW27	RW32	RW33	RW33B	RG2	RG5
	Power type							Diesel		Diesel		Diesel			Diesel		Diesel		Diesel
	Rated load(kg)							3000		3000		3000			3000		3000		3000
	Load center distance(mm)							500		500		500			500		500		500
Characteristics & Dimensions of Forklift Truck	Lifting height(mm)							3000		3000		3000			3000		3000		3000
	Free lift height(mm)							145		145		145			145		145		145
	Fork size(mm) L×W×T							1070×122×45		1070×122×45		1070×122×45			1070×122×45		1070×122×45		1070×122×45
	Mast tilt angle(°)						F/R	6/12		6/12		6/12			6/12		6/12		6/12
	Fork overhang (Wheel center to fork face)(mm)							480		480		480			480		480		480
	Rear overhang(mm)							510		510		510			510		510		510
	Overall dimensions(mm)		Length (To surface of fork)					2750		2750		2750			2750		2750		2750
			Overall width					1225		1225		1225			1225		1225		1225
			Mast closed height					2010		2010		2010			2010		2010		2010
			Mast extended height					4140		4140		4140			4140		4140		4140
			Overhead guard height					2170 (2230*)		2170 (2230*)		2170 (2230*)			2170 (2230*)		2170 (2230*)		2170 (2230*)
	Turning radius (Outside) (mm)							2375		2375		2375			2375		2375		2375
	Min. width of right angle stacking aisle (Including load length and clearance) (mm)							2855		2855		2855			2855		2855		2855
Performance	Speed	Travel speed (No load)( km/h)						19		19		18.5		18	18		18	20	20	19
		Lifting speed (Full load)( mm/sec)						460		380		460			410	430	500	460	460	430
		Lowering speed (Full load) ( mm/sec)						500		500		500			500		500		500
	Max. drawbar pull (Full load)(N)							27000		18400		24600		23100	24500	17600	23600	20700	20300	19500
	Max. gradeability (Full load) (%)							25		15		25		20	25	15	15	20	20	18
Chassis of Forklift Truck	Tyre(mm)			Front				28×9-15-12PR		28×9-15-12PR		28×9-15-12PR			28×9-15-12PR		28×9-15-12PR		28×9-15-12PR
				Rear				6.50-10-10.PR		6.50-10-10.PR		6.50-10-10.PR			6.50-10-10.PR		6.50-10-10.PR		6.50-10-10.PR
	Tread(mm)			Front				1005		1005		1005			1005		1005		1005
				Rear				973.5		973.5		973.5			973.5		973.5		973.5
	Wheelbase(mm)							1760		1760		1760			1760		1760		1760
	Ground clearance		Lowest point					130		130		130			130		130		130
			Wheelbase center					175		175		175			175		175		175
Weight	Dead weight(kg)							4255		4255		4255			4255		4255		4255
	Weight distribution		Full load			F/R		6480/775		6480/775		6480/775			6480/775		6480/775		6480/775
			No load			F/R		1765/2490		1765/2490		1765/2490			1765/2490		1765/2490		1765/2490
Power & Transmission of Forklift Truck	Battery(V/Ah)		Voltage/Capacity (20HR)					12/90		12/90		12/90			12/90		12/90		12/90
	Engine		Model					4TNV94L		C240PKJ-30		4JG2 PE-01	TD27		A498BT1	4TNE92-HRJ	4TNE98-BQFLC		C490BGP	A490BGP
			Manufacturer					YANMAR		ISUZU		ISUZU	UD		XINCHAI	YANMAR	YANMAR		XINCHAI
			Rated output/rpm(kW)					43/2500		34.5/2500		46/2450	38.5/2300		36.8/2400	32.8/2450	44.3/2300		40/2650	37/2650
			Rated torque/rpm(N.m)					205/1000		137.7/1800		186/1700	160/2300		186/1700	149.4/1600	206/1700		162/1800-2000	148/1900
			Quantity of cylinder					4		4		4			4		4		4
			Bore×stroke(mm)					94×110		86×102		95.4×107	96×92		98×105	92×100	98×110		90×105	98×105
			Emission standard					Stage II/Tier2		Stage IIIA		Stage II			E-MARK III	Stage IIIA/Tier4 Interim	Stage IIIA/Tier3		-
			Displacement(cc)					3054		2369		3059	2663		3168	2659	3319		2670	3168
			Fuel tank capacity(L)					70		70		70			70	60	60	60	70
	Transmissions		Manufacturer					CHINA	OKAMURA	CHINA	OKAMURA	CHINA	CHINA		CHINA	CHINA	CHINA	OKAMURA	CHINA
			Type					Power shift	Power shift	Power shift	Power shift	Power shift	Power shift		Power shift	Power shift	Power shift	Power shift	Power shift	Power shift
			Gear		Forward/reverse			1/1	1/1	1/1	1/1	1/1	1/1		1/1	1/1	1/1	1/1	1/1	1/1
Others	Operating pressure		For attachments(MPa)					17.5	17.5	17.5	17.5	17.5	17.5		17.5	17.5	17.5	17.5	17.5
